What is XAR 600 Steel Body Armor Plates?
XAR 600 wear resistant steel plate has many properties such as wear resistance, higher mechanical and chemical properties. In addition to this, it is also an antioxidant and an alloy with unique higher impact toughness. Therefore, it is widely used in extreme wear conditions and can be easily cut and welded, so alloy changes are easy to achieve. It is the best choice for high-performance applications such as petrochemicals. These outstanding products also have higher tensile strength, higher yield strength, higher mechanical strength, etc. The resistance of this product includes resistance to chloride stress cracking corrosion, pitting and crevice corrosion, oxidation resistance, etc. It is also reliable, durable, easy to install and manufacture, has good formability, enhanced impact strength, and more.
XAR 600 Steel Body Armor Plates Parameter:
XAR 600 Bulletproof steel plate chemical compisition:
| Plate Thickness | C | Si | Mn | P | S | Cr | Ni | Mo | B | CEV | CET |
| mm | Max | Max | Max | Max | Max | Max | Max | Max | ppm | typical | typical |
| 8 – 30 | 0.45 | 0.70 | 1.00 | 0.015 | 0.010 | 1.2 | 2.0 | 0.80 | 0.004 | 0.73 | 0.55 |
| 30.1 – 50 | 0.47 | 0.70 | 1.00 | 0.015 | 0.010 | 1.2 | 2.0 | 0.80 | 0.004 | 0.84 | 0.59 |
XAR 600 Alloy Steel Armor Plate mechanical property:
| Hardness [HBW], guarantee | Impact toughness, typical 20 mm | Yield strength | Tensile strength, | Elongation |
| 570 – 640 | 20 J/-40°C (-40 F) | 1650 N/mm2 | 2000 N/mm2 | 7 % |
Features Of Our Wear Resistant XAR 600 Wear Plates:
- Impact resistance: The matrix of XAR 600 armored steel plate is a tough material such as low-carbon steel or low-alloy, stainless steel, etc., which reflects the superiority of bimetallic materials. The wear-resistant layer is resistant to wear media, and the matrix bears the load of the media, so it has good impact resistance. It can withstand the impact and wear of high-drop hoppers in material conveying systems.
- Heat resistance: XAR 600 steel wear plate material is recommended to be used below 600℃. If alloys such as vanadium and molybdenum are added to the wear-resistant layer, it can withstand 800℃. Compared with ordinary carbon steel and low-alloy steel, XAR 600 wear-resistant steel has better performance.
- Corrosion resistance: Contains 100% chromium metal, which has anti-rust and anti-corrosion properties.
XAR 600 Steel Armor Plate Weight Sizes:
XAR 600 Armor Plate Available Sizes:
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. |
||||
XAR 600 Ballistic Steel Armor Plate Available Thickness:
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
XAR 600 Ballistic Steel Plate Application：
- Machinery manufacturing;
- Towers and other building structures;
- Lifting and mobile equipment;
- Bridge construction;
- Wear-resistant plates;
- Frame structures;
- Crane booms;
- Railway cars;
- Stone or iron chutes;
- Truck frames;
- Containers;
- Vehicles and transport equipment;
- Steel structures;
- Anti-drilling plates, such as security doors, shot blasting equipment and tumblers, etc.
