What is XAR 550 Abrasion Resistant Metal?
XAR 550 AR wear plate (super wear resistant) has high load and wear resistance. It is available in various grades and plate thicknesses, tailored to the application. Due to its hardness characteristics, it has a service life at least five times that of conventional structural steel. XAR 550 wear resistant metal grade steel is widely used in engineering applications.
XAR 550 Steel Wear Plate Material Parameter:
XAR 550 armor plate chemical composition:
| C | Si | Mn | P | S | Cr | Mo | Ni | B |
| ≤ 0.35 | ≤ 0.35 | ≤ 1.50 | ≤ 0.025 | ≤ 0.012 | ≤ 1.30 | ≤ 0.50 | ≤ 1.50 | ≤ 0.005 |
XAR 550 armored steel plates mechanical property:
| Hardness at room temperature | Tensile strength | Yield strength | Elongation | Charpy Impact | |
| @Temperature -40.0 °C | @Temperature -40.0 °F | ||||
| 500 – 580 HBW | 1800 MPa, 261000 psi | 1500 MPa, 218000 psi | 8.0 % | 22.0 J | 16.2 ft-lb |
Features of XAR 550 Ballistic Steel Armor Plate:
- Excellent cold formability;
- Abrasion-resistant properties;
- Higher level of wear resistance;
- Cost-effectiveness;
- Excellent surface quality;
- Good weldability and properties;
- High notch strength.
XAR 550 Steel Armor Plate Available Thickness:
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
XAR 550 Ballistic Steel Plate Application Industries:
Some of the key applications are:
- excavating
- mining and earth-moving machinery
- crushing & pulverizing equipment
- truck dump bodies
- conveying
- Hoppers
- Ore Scrapers
- Slide conveyor
- Slurry Pipe Systems
