JFE-EH360A Wear Resistance Steel Sheet

Eh 360 wear plate steel has excellent properties such as wear resistance and low crack resistance. The low temperature toughness of Jfe-eh360 wear resistant plate makes it suitable for various industries.

What is JFE-EH 360 Wear Resistant Steel Plate?

JFE-EH 360 is a standard wear resistant steel. JFE-EH 360 steel plates are designed with premium composition of silicon, manganese, phosphorus, sulfur, chromium and carbon with additions of boron and titanium. JFE EverHard 360 steel plates are not outstanding in strength, but they have excellent wear and tear resistance in different stress inducing systems. These steel plates have high carbon content and are less prone to cracking during welding. Eh 360 steel plates are designed with thickness above 6 mm and with enhanced hardness in the system. This versatile steel plate has a minimum hardness of 361 Brinell.

JFE-EH 360 Wear Plate Steel Parameter:

JFE-EH 360

Grade

Available

thickness

(mm)

Heat treatment

Chemical Composition(%)*

Ceq**

JFE-EH360

6~50

Controlled

Heat treatment

0.20 max

0.55 max

1.60 max

0.030 max

0.40 max

–

0.005~0.020

0.004 max

–

Grade	JFE-EH360
Thickness(mm)	6~50
Brinell hardness(3000) (Average of 5 value)	361min
Thickness (mm)	–
Test temperature (℃)	–
Impact value J (Average of 3 specimens)	–

Main features of JFE-EH 360 wear-resistant steel plate:

JFE-EH 360 wear-resistant steel plate has good durability and long service life;
Good heat resistance, not easy to change color at high temperature;
Has good heat reflectivity;
Good processing performance and spraying performance;
Dimensions and specifications can be customized.

JFE-EH 360 Abrasion Resistant Steel Plate Dimensions Sizes:

		Width (mm)
		2201 ~2400	1801 ~2000	1501 ~ 1800	2601 ~ 2800	2401 ~2600	2001 ~2200	3001 ~ 3200	2801 ~ 3000	3401 ~3600	3201 ~3400
T h i c k n e s s (mm)	9.0~9.9	12	16	18	10	12	14	–	–	–	–
	10.0~11.9	16	20	22	14	14	18	–	12	–	–
	12.0~12.9	16	20	22	14	14	18	–	12	–	–
	13.0~13.9	16	20	22	14	14	18	–	12	–	–
	14.0~22.0	16	20	22	14	14	18	–	12	–	–
	22.1~24.0	20	22	24	16	18	22	12	14	–	–
	24.1~26.0	22	24	25	18	20	22	14	16	–	12
	26.1~28.0	24	25	25	22	22	24	18	20	14	16
	28.1~30.0	25	25	25	24	25	25	20	22	18	20
	30.1~35.0	25	25	25	25	25	25	22	24	22	22
	35.1~40.0	25	25	25	25	25	25	24	25	22	22
	40.1~45.0	25	25	25	25	25	25	25	25	23	24
	45.1~50.8	25	25	25	25	25	25	23	25	20	22
	50.9~60.0	21	23	25	22	24	23	19	20	17	18
	60.1~70.0	18	19	22	19	20	20	16	17	14	15
	70.1~80.0	16	17	19	16	18	17	14	15	13	13
	80.1~90.0	14	15	17	14	16	15	13	13	11	12
	90.1~100.0	12	13	15	13	14	14	11	12	10	10

JFE-EH360 Wear Plates Application：

Stone or iron chutes
Construction of bridges
Lifting and mobile equipment
Framework structures
Truck frames
Crane booms
Machine building
Wearing plates
Rail cars
Pylons and other architectural structures
