What is JEH-EH400 Wear Plate Steel?
JFE EH 400 wear resistant steel plate is widely used in various industries and applications due to its excellent characteristics and performance. In addition to using innovative technologies, GNEE also focuses on manufacturing quality products. We use our efforts and expertise to successfully meet the needs of our customers. We also provide customization of products in different grades, sizes and dimensions, or customers are free to specify their required requirements.
JEH-EH400 Abrasion Resistant Plate Parameter:
| JFE-EH400 Chemical Composition (%) | |||||||||||
| Plate | Heat treatment | C | Si | Mn | P | S | Cr | Ti | Mo | B | Ceq** |
| thickness mm | Controlled heat treatment | max % | max % | max % | max % | max % | max % | max % | max % | max % | typv |
| 5 – 19 | 0.17 | 0.55 | 1.60 | 0.020 | 0.01 | 0.40 | 0.020 | 0.35 | 0.004 | 0.40 | |
| 19.1 – 32 | 0.17 | 0.55 | 1.60 | 0.020 | 0.01 | 0.40 | 0.020 | 0.35 | 0.004 | 0.43 | |
| 32.1 – 60 | 0.17 | 0.55 | 1.60 | 0.020 | 0.01 | 1.20 | 0.020 | 0.50 | 0.004 | 0.58 | |
| Mechanical properties of JFE-EH400 | ||||||
| Brand name | Mechanical Property | Charpy Impact Test | Hardness test | |||
| JFE-EH400 | Yield strength | Tensile strengt | Elongation % | Testing direction | Absorbed energy vE Average J | Brinell hardness (29.42kN) Average of 5 points |
| N/mm2 | N/mm2 | Min % | L | −40°C 61 | 411 | |
| 1058 | 1308 | 23.0 | ||||
Features of JFE-EH400 wear-resistant steel plate:
JFE-EH400 is widely used due to its following characteristics
- Excellent wear resistance
- Extremely high hardness
- Good weldability
- Machinability
- Low temperature toughness
- Superior formability
JFE-EH400 Abrasion Resistant Steel Plate Dimensions Sizes:
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
JFE-EH400 Wear Steel Plates Application Industries
Some of the key applications are :
- Construction
- Automotive Industries
- Cement and Mining
- Chemical Industry
- Hoppers
- Lining for rotary mixers
- Shear liners
- Dredger buckets
- Screens for ores, and switching damper
